The incarnate still features the Ultra slim invest cast wishbone for that added strength and stiffness where it's needed and comes with the Shallower pitched seat tube angle to move the bottom bracket forward making the feel of the bike smaller without changing the top tube length.
13” slammed back end with thickened chain stays, top and Down tube gussets for extra strength out the front, a relatively steep head tube angle at 75.5° to keep front-end tricks responsive. United even added removable brake mounts due to popular demand!
###section###
Product Specs
- MATERIAL: 4130 butted and tapered seamless Japanese Sanko tubing
- HEAD TUBE ANGLE: 75.5°
- SEAT TUBE ANGLE: 70.25°
- CHAIN STAY LENGTH: 13"
- BB HEIGHT: 11.75"
- WHEEL SIZE: 20"
- STANDOVER HEIGHT: 8.75"
- DROPOUT SIZE: 14mm
- HEADSET TYPE: Integrated
- BB TYPE: Mid
- BRAKE MOUNTS: Removable
- GYRO TABS: NA
- WEIGHT: 5lbs
###section###
Product Highlights
- Responsive Geometry with Short Backend and Steep Headtube
- Best suited to Street and Park riding
- High-quality Chromoly construction
- Seamless Japanese Sanko Tubing
- Strong and durable investment cast dropouts
