Fly's Fuego Frame has been totally revamped taking a fresh approach, the Fuego V8 frame is designed to fit different riding styles, whether you're into tech street, all-around riding, or even flatland!
Added an Invest-cast bridge and Yoke to accommodate a short rear end the Fuego now has plenty of clearance for 2.6" tires. On top of all that the standover height has been increased to 9.5", the head tube angle at 76° and the BB height to 11.65".
The 21" version keeps it short at 12.8", striking the perfect balance between stability and a snappy feel. But if you're all about tech street and flat street, the 20.6" size boasts a super short 12.4" rear end. The Fuego V8 also comes loaded with internal and external gussets for extra strength, multi-butted and tapered tubing for an optimal ride, an Investment Cast seat post clamp for added durability, and Dropouts with integrated chain tensioners for hassle-free setup.
###section###
Product Specs
- MATERIAL: 100% Chromoly
- HEAD TUBE ANGLE: 76°
- SEAT TUBE ANGLE: 71°
- CHAIN STAY LENGTH: 12.4"
- BB HEIGHT: 11.65"
- WHEEL SIZE: 20"
- STANDOVER HEIGHT: 9.5"
- DROPOUT SIZE: 14mm
- HEADSET TYPE: Integrated
- BB TYPE: Mid
- BRAKE MOUNTS: Brakeless
- GYRO TABS: None
- WEIGHT: 5.8lbs (2.6kg)
###section###
Product Highlights
- Responsive geometry with short backend and steep headtube
- Great all round frame for all types of riding
- High-quality chromoly construction
- Seamless Japanese Sanko tubing
- Built in chain tensioners
